Argentina IRAM 2073 and 2071 and compatible types (Type I)

The plug and socket used in Class 1 applications in Argentina is defined by IRAM. The applicable standards are: IRAM 2073 “Two pole plugs with earthing contact for domestic and similar purposes, rated 10 A and 20 A, 250 V AC” and IRAM 2071 “Two pole socket—outlets with earthing contact for 10 A and 20 A, 250 V AC., for fixed installations.” It is similar in appearance to the Australasian and Chinese plugs. It has an earthing pin and two flat current-carrying pins forming an upside down V-shape (120°). The flat pins for the 10 A version measure 6.25 by 1.55 mm (0.246 by 0.061 in) and 8.0 by 1.9 mm (0.315 by 0.075 in) for the 20 A version, and are set at 30° to the vertical at a nominal pitch of 7.92 mm (0.312 in). The pin length is the same as in the Chinese version. The earthing pin length is 21.4 mm (0.843 in) for the 10 A version and 21.8 mm (0.858 in) for the 20 A version. The poles plugs length is 18.2 mm (0.717 in) for the 10 A version and 17.8 mm (0.701 in) for the 20 A version. The most important difference from the Australian plug is that the Argentinian plug is wired with the line and neutral contacts reversed.

Argentinian 1996 power plug arrangement
In Brazil, similar plugs and sockets are still commonly used for high-power appliances like air conditioners, dishwashers, and household ovens. Although being often called “Argentinian plug,” it is actually based on the American NEMA 10-20 standard, and is incompatible with Argentinian IRAM plugs. Since Brazil adopted the NBR 14136 standard which includes a 20 A version, the original motivation to use the NEMA 10-20 plug has ceased to exist
