Israel Power Cords, Electrical Plug, Flexible Cable, Sockets Standard Plug and socket – outlet for household and similar purposes: plugs and sockets for single phase up to 16A – General requirements Israel standard. The plug defined in SI 32 (IS16A-R) is used only in Israel, the Gaza Strip and the West Bank. There are two versions: an older one with flat pins, and a newer one with round pins. In 1989 the standard was revised, with three round 4.5 mm (0.177 in) pins in the same locations designed to allow the socket to accept both older and newer Israeli plugs, and also non-grounded Europlugs (often used in Israel for equipment which does not need to be grounded and does not use more current than the Europlug is rated for).
Contents
-
- ➡️Plug Guide
- ➡️Power Cords
- ➡️Extension Outlet
- ➡️Flexible Cables
- ➡️Standards & Compliance
- ➡️Reference
➡️Plug Guide SII STANDARDIZED PLUGS
The plug defined in SI 32 (IS16A-R) is used only in Israel and in territories of the State of Palestine (the West Bank and the Gaza Strip).update plugs with round pins. In 1989 new standard was publisehd, with three round 4.5 mm (0.177 in) pins in the same locations designed to allow the socket to accept both older and newer Israeli plugs, and non-earthed Europlugs (often used in Israel for equipment which does not need to be earthed and does not use more current than the Europlug is rated for). Pre-1989 sockets which accept only old-style plugs have become very rare in Israel. SI 32 plugs have no sleeve insulation, so when a plug is partially removed its prongs may still be powered although they can be touched by small fingers, metal objects, etc., with a risk of electric shock. Sockets have a defined polarity; if properly installed, looking at the front Neutral is to the left, Earth at the bottom, and Line to the right
➡️Power Cords
Israel power cord products with SII certification are manufactured to SI32 and IEC standards,designed for Israel power cord applications,We are producing Israel power cords in standard configurations and can make any custom version as well.100% of our Israel SII power cords are fully molded with high quality cords with RoHS and REACH compliant as We are China leading Israel power cords manufacturer and supplier providing cheapest prices of Israel SII approved ac power cords products with plug with IEC C7,C5,C13,C15,C19 power supply cords.
IEC 60320 Connectors
IEC 60320 power cables come in normal and high-temperature variants, as well as various rated currents. The connectors have slightly different shapes to ensure that it is not possible to substitute a cable with a lower temperature or current rating, but that it is possible to use an overrated cable. Cords also have different types of exterior jackets available to accommodate environmental variables such as moisture, temperature, oils, sunlight, flexibility, and heavy wear. For example, a heating appliance may come with a cord designed to withstand accidental contact with heated surfaces.
Extension Outlet
Israel Power Strips are manufactured to Israel SI-32 standards for AC extension cord applications. We products types of socket with 3-outlet, 4-outet,5 outlets, 6-outlet, 8-outlets, 10-outlets power strips in standard configurations and can make any custom version as well.Israel Power Strip Manufacturer Power Strip sockets with Israel 16A Ampere 250 Volt , SL-32 sockets, 2 pole-3 wire grounding Custom power cable length cord, 2-pole switch, USB charging ports for use in Israel and Gaza.,Great for TV’s, DVD Players, VCR’s, Computers, Telephones, Fax Machines, Modems, Satellite Receivers etc.
➡️Flexible Cable
Israel flexible cables are same as European power cables.
PVC Cables: H03VV-F，H03VVH2-F, H05VV-F，H05VVH2-F
High Temperature 90°C：H03V2V2-F，H03V2V2H2-F，H05V2V2-F，H05V2V2H2-F
LSZH Cables: H03Z1Z1-F，H05Z1Z1-F
Rubber Cables: H05RN-F，H05RR-F，H07RN-F
Waterproof Cables: H07RN8-F
Single Core Non-sheathed cable for decorative chains: H03VH7-H
Non-sheathed cable for internal wiring for conductor temperature of 90°C: H05V2-K , H07V2-K
Photovoltaic Systems Cables: PV1-F
Cableso proudly offers a huge variety of 0.5mm2 through 4mm2 EU type VDE certified bulk power cord wire. All our European bulk flexible wire products are extruded in house in high volume and we offer the most competitively priced high quality China portable cables in 2, 3, 4 and 5 conductor 300V and 600V styles.
Standards & Compliance
SI 32 Standard
The Type H plug is defined in SI 32, Israel’s mandatory standard for plugs and socket-outlets for household and similar purposes. The original SI 32 design used three flat pins in a Y-shape, but the standard was revised in 1989 to use three round 4.0–4.5mm pins in the same positions. Modern Type H plugs are compatible with both older flat-pin and newer round-pin Israeli sockets.
Regulatory update — effective 8 August 2026: Israel’s Ministry of Economy has published the third amendment to Mandatory Standard SI 32 Part 1.1 in Government Gazette No. 12252, covering safety requirements for single-phase plugs and socket-outlets up to 16A. This amendment enters into force on 8 August 2026. Our production processes are aligned with the updated requirements, including the removal of certain insulation dimension requirements that were previously mandatory.
SII Certification
SII (Standards Institution of Israel) certification is mandatory for all power cords and plugs entering the Israeli market. The certification process requires documentation review, product testing, and factory compliance checks — it is not a self-declaration system. Key SII requirements for power cords include:
- Mains plug must comply with SI 32
- Cable must comply with SI 473 (Israeli cable standard)
- Wire color scheme must comply with SI 544
Our factory holds SII approval for Type H power cordsets and can provide certification documents, test reports, and factory audit support for every shipment.
Testing performed on each production batch includes: electrical strength (Hi-Pot dielectric withstand), temperature rise, bending and pull tests, insulation resistance, continuity, polarity, and grounding integrity.
